TP-Link SafeStream TL-ER6020 Gigabit Broadband Desktop/Rackmount VPN Router, 940M NAT throughput, 40k Concurrent Sessions, 64 IPSec VPN Tunnels, VLAN, Multi-NAT, 4 WAN Load balance or auto failover
- 2 Gigabit WAN ports, 2 Gigabit LAN ports, 1 Gigabit LAN/DMZ port and a console port
- Supports multiple VPN protocols including IPsec/PPTP/L2TP, which helps users establish their VPN more flexibly
- Supports up to 50 IPsec VPN tunnels with a hardware-based VPN engine
- Abundant security features including ARP Inspection, DoS Defense, URL/Keyword Domain Filter and Access Control
- Deploys One-Click restriction of IM/P2P applications to manage staff online behavior
- Professional 4kV lightning protection keeps your investments as safe as possible
-1200x1200.jpg "TP-Link SafeStream TL-ER6020 Gigabit Broadband Desktop/Rackmount VPN Router, 940M NAT throughput, 40k Concurrent Sessions, 64 IPSec VPN Tunnels, VLAN, Multi-NAT, 4 WAN Load balance or auto failover")
-1200x1200.jpg "TP-Link SafeStream TL-ER6020 Gigabit Broadband Desktop/Rackmount VPN Router, 940M NAT throughput, 40k Concurrent Sessions, 64 IPSec VPN Tunnels, VLAN, Multi-NAT, 4 WAN Load balance or auto failover")
Share Product
- Availability:
- In Stock
- Product Code:
- TL-ER6020
- Brand:
- TP-Link
JOD 89.00
Chat with us on Whatsapp
-
Free delivery on orders Over 100 JOD
-
Cash on Delivery
TP-Link-ER6020 - Gigabit router for high performance
Router TP-Link-ER6020 guarantees high performance, providing support for advanced features such as VPN IPsec/ PPTP/ L2TP, bandwidth balancing, access control, instant messenger/ P2P blocking, DoS attack protection and bandwidth control. This router is suitable for small and medium businesses, hotels and other larger groups of users needing a powerful, secure and manageable network.
Business-class equipment
With a dual core 64-bit network processor, the TL-ER6020 Gigabit Router can handle any challenge and work on multiple tasks simultaneously. The router supports multiple VPN protocols such as IPsec, PPTP and L2TP in client/server modes, as well as VPN passthrough. The device offers hardware-based connection support for up to 64 LAN-to-LAN/ Client-to-LAN IPsec VPN connections simultaneously. It provides DES/ 3DES/ AES128/ AES192/ AES256 encryption, MD5/ SHA1 authentication, IKE/ manual key management and two Main/ Aggressive negotiation modes.
It will meet every requirement
The TL-ER6020 has one WAN port and three WAN/LAN ports. The intelligent bandwidth load balancing system can distribute the transmitted data depending on the parameters connected to each of the WAN ports in such a way as to properly use the total available transfer. IP-based bandwidth control allows administrators to optimize network performance. The router is designed to be lightning resistant up to 4 Kv. The device protects computer bands from the effects of large voltage spikes, so it is a safe solution, especially in industrial networks.
Features of TP-Link TL-ER6020:
- 1 Gigabit WAN port, 3 Gigabit WAN/ LAN ports, 1 Gigabit LAN port
- Multi-protocol VPN configuration possible, including IPsec/ PPTP/ L2TP
- With hardware-based VPN support, up to 64 IPsec tunnels can be created simultaneously
- Extensive security features: ARP Inspection, protection against DoS attacks, URL/keyword filtering, access control.
- Welcome Page Authentication
- Advanced 4 kV surge protection to protect the device from damage
Specification
Specification
Standards and protocols
IEEE 802.3, IEEE802.3u, IEEE802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
Ports
1 Gigabit WAN port 3 Gigabit LAN/WAN ports 1 Gigabit LAN port
Network cabling
10 BASE-T: UTP cable cat. 3, 4, 5 (max. 100 m) EIA/TIA-568 100 Ω STP (max. 100 m) 100 BASE-TX: Cat 5, 5e UTP cable (max. 100 m) EIA/TIA-568 100 Ω STP (max. 100 m) 1000 BASE-T: Cat 5, 5e, 6 UTP cable (max. 100 m)
Buttons
Reset
Power supply
Built-in universal power supply AC100-240 V~ 50/60 Hz at input
Flash Memory
32 MB
DRAM memory
DDRIII 256 MB
LEDs
PWR, SYS, Link/ Act, Speed
Dimensions (S x G x W)
294 × 180 × 44 mm
Number of concurrent sessions
40000
NAT capacity
940 Mb/s
IPsec VPN throughput (3DES)
99 Mb/s
WAN connection type
Dynamic/Static IP, PPPoE/ Russian PPPoE, PPTP/ Russian PPTP, L2TP /Russian L2TP, BigPond
DHCP
DHCP server/client DHCP reservation
MAC address cloning
Possibility to change MAC addresses
IPTV
Bridge, your own
IPv6
IPv6 support
VLAN
802.1Q VLAN, VLAN port
IPsec VPN
64 IPsec VPN tunnels LAN-to-LAN, Client-to-LAN 2 negotiation modes - Main/ Aggressive DES, 3DES, AES128, AES192, AES256 encryption Authentication MD5, SHA1 IPsec NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS)
PPTP VPN
16 PPTP VPN tunnels PPTP VPN client/server PPTP with MPPE encryption
L2TP VPN
16 L2TP VPN tunnels L2TP VPN client/server L2TP over IPse
VPN Pass-through
IPsec (ESP), PPTP, L2TP
Protection against network attacks
Protection against TCP/UDP/ ICMP Flood attacks TCP scan blocking (Stealth FIN/ Xmas/Null) WAN-side ping blocking
Filtering
Filtering of MAC addresses URL/keyword filtering
Protection against ARP attacks
Sending GARP packets LAN/WAN side ARP scanning IP-MAC address binding
Access Control
Blocking based on target/source IP addresses
Services
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Support
Management via web interfaces Remote management Export/import configuration SNMP Diagnostics (Ping and Traceroute) NTP synchronisation System Log
Certificates
CE, FCC, RoHS
Package contents
TL-ER6020 Power Cable Assembly kit Manual
System requirements
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux
Working environment
Permissible operating temperature: 0℃~40℃ (32℉~104℉) Permissible storage temperature: -40℃~70℃ (-40℉~158℉) Permissible air humidity: 10%~90%, non-condensing Permissible storage humidity: 5%~90%, non-condensing
