General | |
---|---|
Device Type | UPS - Power Factor Correction (PFC) - rack-mountable / external |
Power Device | |
---|---|
UPS Technology | On-line |
Input Voltage | AC 230 V |
Input Voltage Range | AC 115 - 280 V |
Frequency Provided | 50/60 Hz |
Frequency Required | 40 - 70 Hz |
Input Connectors | 1 x power IEC 60320 C20 |
Power Output Connectors Details | 6 x power IEC 60320 C13 | 1 x power IEC 60320 C19 |
Output Voltage | AC 200/208/220/230/240 V ± 3% - 50/60 Hz |
Power Capacity | 2700 Watt / 3000 VA |
Output Waveform | Sinewave |
Surge Suppression | Yes |
Circuit Protection | Circuit breaker |
Efficiency | 88% |
Power Factor (PF) | 0.9 |
Battery | |
---|---|
Quantity | 6 |
Technology | Lead acid |
Voltage Provided | 12 V |
Capacity | 9 Ah |
Run Time (Up To) | 3 min at full load |
Recharge Time | 3 hour(s) |
Features | Spill-proof |
Networking | |
---|---|
Remote Management Interface | RS-232, USB |
Expansion / Connectivity | |
---|---|
Interfaces | 1 x management (USB) | 1 x RS-232 |
Expansion Slots | 1 (total) / 1 (free) x Liebert IntelliSlot |
Miscellaneous | |
---|---|
Included Accessories | Tower stand |
Cables Included | USB cable - external - 4 ft | Serial cable - external - 6.6 ft | 3 x power cable - external - 6.6 ft | 2 x power cable - external - 8 ft | Power cable - external |
Rack Mounting Kit | Included |
Features | Audible alarm, internal bypass, cooling fan |
Compliant Standards | CISPR 22 Class A, GS, IEC 61000-4-5, ISO 14001, EN 61000-4-5, IEC 62040-2, WEEE, EN 62040-2, IEC 62040-1, EN 62040-1 |
Software / System Requirements | |
---|---|
Software Included | Liebert MultiLink |
Environmental Standards | |
---|---|
ENERGY STAR | Yes |
Environmental Parameters | |
---|---|
Min Operating Temperature | 32 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 0 - 95% (non-condensing) |
Dimensions & Weight | |
---|---|
Width | 16.9 in |
Depth | 23.7 in |
Height | 3.3 in |
Weight | 71.43 lbs |
Dimensions & Weight (Shipping) | |
---|---|
Shipping Width | 22.4 in |
Shipping Depth | 28.2 in |
Shipping Height | 10.3 in |
Shipping Weight | 85.98 lbs |
