TP-Link Omada ER706WP-4G AX3000 Wi-Fi 6 4G+ Cat6 Gigabit VPN Gateway with 4-Port PoE+

The TP-Link Omada ER706WP-4G is an all-in-one business gateway combining 4G+ Cat6 mobile connectivity, AX3000 dual-band Wi-Fi 6, Gigabit routing, VPN capabilities and four PoE+ output ports. Two Nano SIM slots support mobile-network redundancy, while 4G+ Cat6 provides download rates up to 300 Mbps and upload rates up to 50 Mbps.

The gateway delivers wireless signal rates up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz. Its wired interfaces include a Gigabit SFP WAN/LAN port, one Gigabit WAN port and four Gigabit LAN/WAN ports, with the four LAN/WAN RJ45 ports supporting PoE+ output from a shared 45 W PoE budget.

Key Features

• 4G+ Cat6: Dual Nano SIM support with mobile data rates up to 300 Mbps download and 50 Mbps upload.
• AX3000 Wi-Fi 6: Up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz with HE160, OFDMA, MU-MIMO and Beamforming.
• 4-Port PoE+ Output: Four Gigabit PoE+ ports support IEEE 802.3af/at devices with a shared 45 W PoE budget.
• Flexible Gigabit Networking: Includes Gigabit SFP WAN/LAN, dedicated Gigabit WAN and four Gigabit LAN/WAN RJ45 ports.
• Business VPN Gateway: Supports IPSec, SSL, WireGuard, OpenVPN, PPTP, L2TP and GRE VPN technologies.
• Omada Centralized Management: Supports Omada cloud-based, hardware and software controllers together with the Omada app.

Technical Specifications

Compatibility & Important Information

• The ER706WP-4G uses two Nano SIM slots for 4G+ Cat6 connectivity and supports SIM failover for network continuity; the two SIM connections should not be interpreted as simultaneous aggregated mobile links.
• The four Gigabit LAN/WAN RJ45 ports provide PoE+ output with a shared maximum PoE budget of 45 W for compatible IEEE 802.3af/at powered devices.
• Wi-Fi 6 functions including OFDMA, HE160 and 1024-QAM require compatible client devices. The 160 MHz channel width applies to the 5 GHz band and availability depends on regional regulations.
• Omada Mesh requires compatible Omada EAP access points supporting mesh functionality.
• 4G performance depends on mobile-network coverage, service plan, network capacity, equipment and environmental conditions.
• The official specification lists EU LTE bands including LTE-FDD B1/B3/B5/B7/B8/B20/B28/B32 and LTE-TDD B38/B40/B41; SIM and carrier compatibility should match the network bands used by the service provider.

Package Contents

• 1 × TP-Link Omada ER706WP-4G Gateway
• 1 × Power Adapter
• 1 × Quick Installation Guide
