MSI PRO Z890-P WiFi6E Motherboard Supports Core Ultra Series 2 Intel Processors, LGA 1851, DDR5, 5Gbps LAN, USB Type-C, Wi-Fi 6E, Bluetooth 5.3
- • Intel Z890 Platform: LGA 1851 motherboard supporting Intel Core Ultra Processors (Series 2)
- • DDR5 Memory: 4 UDIMM slots, up to 256GB capacity and up to 9200+ MT/s overclocked memory support
- • PCIe & Storage: PCIe 5.0 x16, 4 M.2 slots including PCIe 5.0 x4, and 4 SATA 6G connectors
- • Networking: Realtek 8126 5Gbps LAN, Wi-Fi 6E and Bluetooth 5.3
- • USB Connectivity: Rear USB 10Gbps Type-C and front USB 20Gbps Type-C support
Share Product
- Availability:
- In Stock
- Product Code:
- PRO Z890-P WIFI6E
- Brand:
- MSI
JOD 219.00
Chat with us on Whatsapp
Chat with us on Whatsapp - Hosting
-
Free delivery on orders Over 100 JOD
-
Cash on Delivery
The MSI PRO Z890-P WIFI6E is an ATX motherboard based on the Intel Z890 chipset and LGA 1851 socket, supporting Intel Core Ultra Processors (Series 2). It combines DDR5 memory support with PCIe 5.0 expansion, four M.2 storage slots and a practical connectivity layout for modern desktop systems.
Integrated connectivity includes Realtek 8126 5Gbps LAN, Wi-Fi 6E, Bluetooth 5.3 and front USB 20Gbps Type-C support. The board also features a 14+1+1+1 power design with 55A DrMOS, dual 8-pin CPU power connectors, an Extended Heatsink and MSI EZ DIY features.
Key Features
- Intel Z890 Platform: LGA 1851 socket supporting Intel Core Ultra Processors (Series 2).
- DDR5 Memory: Four DDR5 UDIMM slots with up to 256GB capacity and overclocked memory speeds up to 9200+ MT/s.
- PCIe 5.0 Expansion: Primary CPU-connected PCIe x16 slot supports PCIe 5.0 x16.
- High-Speed Storage: Four M.2 slots including one PCIe 5.0 x4 slot, plus four SATA 6G connectors.
- Integrated Networking: Realtek 8126 5Gbps LAN, Wi-Fi 6E and Bluetooth 5.3.
- USB Connectivity: Rear USB 10Gbps Type-C and front USB 20Gbps Type-C support.
Technical Specifications
| Component | Specification |
| Brand | MSI |
| Model | PRO Z890-P WIFI6E |
| Chipset | Intel Z890 |
| CPU Socket | LGA 1851 |
| CPU Support | Intel Core Ultra Processors (Series 2) |
| Memory Slots | 4 × DDR5 UDIMM |
| Maximum Memory | 256GB |
| Memory Support | DDR5 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s |
| Memory Features | Intel XMP 3.0, memory overclocking, Dual-Controller Dual-Channel mode, Non-ECC un-buffered memory, CUDIMM support |
| Expansion Slots | 3 × PCIe x16, 1 × PCIe x1 |
| Primary PCIe Slot | PCIe 5.0 x16 from CPU |
| Additional PCIe Slots | PCIe 4.0 x1, 2 × PCIe 4.0 x4 |
| M.2 Storage | 4 × M.2; 1 × PCIe 5.0 x4 and 3 × PCIe 4.0 x4, with SATA mode support on M.2_4 |
| SATA | 4 × SATA 6G |
| RAID | RAID 0 / 1 / 5 / 10 for SATA and M.2 NVMe storage |
| LAN | Realtek 8126 5Gbps LAN |
| Wi-Fi | Wi-Fi 6E, 2.4 GHz / 5 GHz / 6 GHz, up to 2.4Gbps |
| Bluetooth | Bluetooth 5.3 |
| Audio | Realtek ALC897, 7.1-Channel High Definition Audio |
| Display Outputs | HDMI 2.1 up to 4K 60Hz, DisplayPort 1.4 up to 4K 60Hz |
| Rear USB | 4 × USB 2.0, 2 × USB 5Gbps Type-A, 1 × USB 10Gbps Type-A, 1 × USB 10Gbps Type-C |
| Front USB Support | 4 × USB 2.0, 4 × USB 5Gbps Type-A, 1 × USB 20Gbps Type-C |
| Power Design | 14+1+1+1 Duet Rail Power System with 55A DrMOS |
| Form Factor | ATX |
| Dimensions | 243.84 × 304.8 mm |
| Operating System | Windows 11 64-bit |
Compatibility & Important Information
- CPU compatibility is for Intel Core Ultra Processors (Series 2) using the LGA 1851 socket.
- This motherboard uses DDR5 memory. Supported memory speed varies according to the installed CPU, memory modules and DIMM configuration.
- The primary CPU-connected expansion slot supports PCIe 5.0 x16.
- M.2_1 supports PCIe 5.0 x4 2280 and 2260 devices; the other three M.2 slots support PCIe 4.0 x4, with M.2_4 also supporting SATA mode.
- HDMI and DisplayPort motherboard video outputs require a processor featuring integrated graphics.
- Wi-Fi 6E 6 GHz availability depends on local regulations.
| Motherboard Specifications | |
|---|---|
| CPU Support | Intel® Core™ Ultra Series 2 CPU |
| CPU Socket Type | LGA 1851 |
| Chipset | INTEL Z890 |
| Form Factor | ATX |
| Memory Type | DDR5 |
| Memory Speed | 9200 MHz |
| Maximum Memory | 256 GB |
| Memory Slots | 4 Slots |
| M.2 Slots | Yes |
| Wireless LAN | Yes |
| Warranty | |
| Warranty | 1 Year |
Q: Which processors are compatible with the MSI PRO Z890-P WIFI6E?
A: MSI specifies support for Intel Core Ultra Processors (Series 2) using the LGA 1851 socket.
Q: Does this motherboard support DDR5 memory?
A: Yes. It has four DDR5 UDIMM slots with a maximum capacity of 256GB and supports memory overclocking and Intel XMP 3.0.
Q: What is the maximum supported DDR5 speed?
A: MSI specifies up to 9200+ MT/s in a 1DPC 1R overclocked configuration. Supported speeds vary according to the CPU and memory configuration.
Q: Does it support PCIe 5.0 graphics cards?
A: The primary CPU-connected PCIe x16 slot supports PCIe 5.0 x16.
Q: How many M.2 SSD slots are available?
A: There are four M.2 slots. M.2_1 supports PCIe 5.0 x4, while M.2_2, M.2_3 and M.2_4 support PCIe 4.0 x4. M.2_4 also supports SATA mode.
Q: Does the motherboard include Wi-Fi and Bluetooth?
A: Yes. A Wi-Fi 6E module is pre-installed and supports 2.4 GHz, 5 GHz and 6 GHz bands up to 2.4Gbps, together with Bluetooth 5.3.
Q: What wired network connection does it provide?
A: The motherboard uses a Realtek 8126 controller for 5Gbps LAN connectivity.
Q: Do the HDMI and DisplayPort outputs work with every compatible processor?
A: No. MSI specifies that the onboard HDMI and DisplayPort outputs require a processor featuring integrated graphics.
