IMOU VDP7 5MP 2-Wire Video Doorphone Kit with 7-inch Touch Screen - VO1-5M0R / VH1-7A0S

The IMOU VDP7 is a smart 2-wire video doorphone system combining a 5 MP door station with a 7-inch indoor touchscreen. The door station captures video at up to 2880 x 1620 resolution with a wide 149° diagonal field of view and up to 15 m infrared night vision for clear visitor monitoring during day and night.

Designed for convenient access control, the VDP7 supports card, password, indoor monitor and Imou Life app unlocking, along with two independent lock-control channels. Dual-band Wi-Fi 6, two-way audio, Human, Vehicle and Loitering Detection, local MicroSD storage up to 512 GB and configurable Do Not Disturb operation provide a complete smart entrance-management solution.

Key Features

• 5 MP Door Station: 2880 x 1620 maximum resolution with a 2.3 mm lens and wide 149° diagonal field of view.
• 7-inch Touchscreen: Indoor monitor provides a 1024 x 600 touch display for visitor viewing, communication and access control.
• Multiple Unlocking Methods: Supports card, password, indoor monitor and Imou Life app access control.
• Smart Detection: Human, Vehicle and Loitering Detection help provide more relevant entrance notifications.
• Dual-Band Wi-Fi 6: Supports both 2.4 GHz and 5 GHz wireless networking with IEEE 802.11b/g/n/ax connectivity.
• Two-Way Communication: Two-way audio enables direct communication between residents and visitors.

Technical Specifications

Compatibility & Important Information

• This listing is for the standard VDP7 2-wire system and should not be confused with the separate VDP7 PoE configuration.
• The VDP7 supports dual-band 2.4 GHz and 5 GHz Wi-Fi 6 connectivity.
• Compatible electric-lock installation must follow the IMOU wiring requirements and the supported lock-control interfaces.
• The system provides two lock-control channels and two exit-button channels for suitable entrance installations.
• Local video storage requires a compatible MicroSD card with capacity up to 512 GB.
• Remote viewing, two-way communication and app-based unlocking use the Imou Life app on supported iOS and Android devices.

Package Contents

• Door Station (VTO) x 1
• Wall Mounting Bracket for VTO, Pre-Installed x 1
• Drilling Template for Door Station x 1
• Indoor Monitor (VTH) x 1
• Wall Mounting Bracket for Monitor x 1
• Drilling Template for Monitor x 1
• Adapter x 1
• 2-Pin Power Cable x 1
• Female Wire Harness x 1
• Screw Pack x 2
• Wires and Connectors Pack x 1
• L-Shaped Wrench x 1
• Name Tag x 2
• Card x 3
• Quick Start Card x 1
• Regulatory Information x 1
