ASUS TUF Gaming 1000W Gold EVO 1000 W ATX 3.1 Power Supply

The ASUS TUF Gaming 1000W Gold EVO is a 1000 W ATX power supply designed for modern gaming and performance desktop systems. It combines ATX 3.1 compliance and PCIe 5.1 compatibility with a native 12V-2x6 connection for compatible graphics hardware.

Built for durability, the TUF Gaming Gold EVO design uses military-grade components, protective PCB coating and a 135 mm dual-ball-bearing fan. The 1000 W model is certified 80 PLUS Gold, Cybenetics Platinum at 230 V and Cybenetics Lambda A- for acoustic performance.

Key Features

• 1000 W Output: Provides 1000 W total output with up to 83.33 A / 1000 W on the +12 V output.
• ATX 3.1 & PCIe 5.1: Supports current power-delivery standards and compatible PCIe 5.1 graphics cards.
• Native 12V-2x6: Provides one PCIe 16-pin 12V-2x6 connection with a matching PCIe Gen 5.1 cable.
• Certified Efficiency: 80 PLUS Gold with Cybenetics Platinum certification at 230 V.
• TUF Durability: Military-grade components and protective PCB coating support long-term reliability.
• 135 mm Dual-Ball-Bearing Fan: Durable fan design with Cybenetics Lambda A- acoustic certification.

Technical Specifications

Compatibility & Important Information

The TUF Gaming 1000W Gold EVO meets the ATX 3.1 standard and supports PCIe 5.1 graphics cards. It provides one native PCIe 16-pin 12V-2x6 connection plus three PCIe 6+2-pin connections for compatible graphics hardware.

The PSU measures 150 × 150 × 86 mm. Chassis installation should provide sufficient space for the power supply and connected modular cables.

This model does not include 0dB technology or Aura Sync lighting. ASUS specifies a 135 mm dual-ball-bearing fan for cooling.

Package Contents

• 1 × Power Cord
• 1 × 610 mm Motherboard Power Cable
• 2 × 750 mm CPU Cables
• 1 × 500 mm PCIe Gen 5.1 16-Pin-to-16-Pin Cable
• 3 × 500 mm PCIe 8-Pin-to-6+2-Pin Cables
• 2 × SATA 1-to-3 Cables, 400 + 120 + 120 mm
• 1 × Peripheral 1-to-3 Cable, 400 + 120 + 120 mm
• 3 × TUF Gaming Cable Ties
• 1 × Chassis Screws Package
• 1 × User Manual
